Scientists at Technion in Israel figured out how to harvest the electrons plants produce and extract the current. By collecting electrons naturally transported within plant cells, the scientists can generate electricity as part of a ‘green,’ biological solar cell. Now the research team has used a succulent plant to create a living ‘bio-solar cell’ that runs on the solar powered photosynthesis.
The team reported their study in ACS Applied Materials & Interfaces.
Though plants can serve as a source of food, oxygen and décor, they’re not often considered to be a good source of electricity. But by collecting electrons naturally transported within plant cells, scientists can generate electricity as part of a “green,” biological solar cell.
In all living cells, from bacteria and fungi to plants and animals, electrons are shuttled around as part of natural, biochemical processes. But if electrodes are present, the cells can actually generate electricity that can be used externally.
Previous researchers have created fuel cells in this way with bacteria, but the microbes had to be constantly fed. Instead, scientists, including Noam Adir’s team, have turned to photosynthesis to generate current.
During this process, light drives a flow of electrons from water that ultimately results in the generation of oxygen and sugar. This means that living photosynthetic cells are constantly producing a flow of electrons that can be pulled away as a “photocurrent” and used to power an external circuit, just like a solar cell.
Certain plants – like the succulents found in arid environments – have thick cuticles to keep water and nutrients within their leaves. Yaniv Shlosberg, Gadi Schuster and Adir wanted to test, for the first time, whether photosynthesis in succulents could create power for living solar cells using their internal water and nutrients as the electrolyte solution of an electrochemical cell.
The team created a living solar cell using the succulent Corpuscularia lehmannii, also called the “ice plant.” They inserted an iron anode and platinum cathode into one of the plant’s leaves and found that its voltage was 0.28V. When connected into a circuit, it produced up to 20 µA/cm2 of photocurrent density, when exposed to light and could continue producing current for over a day.
Though these numbers are less than that of a traditional alkaline battery, they are representative of just a single leaf. Previous studies on similar organic devices suggest that connecting multiple leaves in series could increase the voltage.
The team specifically designed the living solar cell so that protons within the internal leaf solution could be combined to form hydrogen gas at the cathode, and this hydrogen could be collected and used in other applications. The researchers say that their method could enable the development of future sustainable, multifunctional green energy technologies.
The authors acknowledge funding from a “Nevet” grant from the Grand Technion Energy Program (GTEP) and a Technion VPR Berman Grant for Energy Research and support from the Technion’s Hydrogen Technologies Research Laboratory (HTRL).
Well, this qualifies as something out at the edge and has existed without great attention. A whole field has been opened up and the field has been out there since shortly after life got going on the planet.
While the bit over a quarter volt isn’t “impressive”, many processors and memory chips are running at under one volt now. An alkaline battery at a medium charge only has a 1.5 volt output.
It's likely that this research will get some notice and improvements. It will take a while before we see more as this team’s research has just cracked open the field.
So congratulations are in order!! And a complimentary “How about that!” notice. It will be fascinating to see how this technology develops.
By New Energy and Fuel
